| Model Number: | 12'',14'' |
|---|---|
| Packaging Details: | wooden case |
| Delivery Time: | 2 weeks-1 month |
| Standard: | ANSI, DIN, JIS, ASME | Application: | Application |
|---|---|---|---|
| Pressure: | Class150/300/600/9001500/2500 | Surface: | Black Painting / Anti-rust Oil / Galvanized |
| Color: | As Per Requirement | Technics: | Forged |
| High Light: | CNC double blind flange,ASME double blind flange,ANSI Carbon Steel Flange |
||
forged carbon steel plain flange
1. ANSI B16.5, ASME B16.47 FLANGE
Size range: 1/2" to 80" DN15 to DN2000
Design: welding neck, slip on, blind, socket welding, threaded, lap-joint
Pressure: 150#, 300#, 600#,900#,1500#, 2500#
Wall thickness for welding neck flange: STD, SCH40, SCH80, SCH160. SCHXXS
Material: carbon steel A105, stainless steel 304/304L, 316/316L
Coating: black paint, yellow transparent paint, cold and hot dip galvanize
Package: seaworthy plywooden case, wooden pallet
2. EN1092-1 FLANGE
Size range: DN15 to DN2000
Design: type01 plate flange, type02 loose flange, type05 blind flange, type11 welding necking
type12 slip on flange, type 13 threaded flange
Pressure: PN6, PN10, PN16, PN25, PN40, PN64, PN100
Material: carbon steel C22.8, S235, S235JR, P235GH, stainless steel: 304/304L, 316/316L
Coating: black paint, yellow transparent paint, cold and hot dip galvanize
Package: sea worthy plywooden case, wooden pallet
3. DIN FLANGE
Size range: DN15 to DN2000
Design: slip on flange DIN2573,2576,2502,2503, 2543,2545
welding neck falnge DIN2631, 2632,2633,2634,2635
blind flange DIN 2527 PN6, PN10, PN16, PN25, PN40
threaded falnge DIN2565,2566,2567,2567
loose flange DIN 2641,2642,2656,2673
Material: carbon steel ST37.2, stainless steel 1.4301, 1.4404
Coating: rust-proof oil, transparent paint, cold and hot galvanize
Package: sea worthy plywooden case, wooden pallet
4. GOST FLANGE
Size range: DN15 to DN 2000
Design : plate falnge 12820-80, welding neck flange 12821-80
Pressure: PN6, PN10, PN16, PN25, PN40
Material: carbon steel CT-20, stainless steel 304/304L, 316/316L
Coating: rust-proof oil, cold and hot galvanize
Package: sea worthy plywooden case, wooden pallet
5) JIS FALNGE
Size ragne : 15A to 2000A
Design: SOP, BIND, SOH,
Puressure: 1K, 2K, 5K, 10K, 16K, 20K, 30K, 40K
Material: carbon steel SS400, stainless steel SUS304, SUS316
Coating : rust-proof oil, cold and hot galvanize
Packing: sea worthy plywooden case, wooden pallet
Material: Carbon steel: ASTM A105,A350 LF2, A694 etc.
Stainless steel: ASTM A182 F304 , 304L,,F304L,F316,316L , AISI 304 , AISI 321
Alloy steel: ASTM A182 A182 F12,F11,F22,F5,F9,F91etc.
| Size |
ASME B16.5:1/2"-24" ASME B16.47:26"-48" |
|
| Rating | 150LB/300LB/600LB/900LB/1500LB/2500LB | |
| Standard | ASME B16.5, ASME B16.47A, ASME B16.47B, MSS SP 44, DIN 2632, DIN2633, DIN2634, DIN2635, DIN2636, JISB2220, BS4504, GB, etc | |
| Material |
|
|
| Surface | Black Painting / Anti Rust Oil / Hot Dip Galvanized | |
| Packing | Plywood cases, pallets, or as per your request. | |
