| Model Number: | 1/2'' |
|---|---|
| Packaging Details: | wooden case |
| Delivery Time: | 2 weeks-1 month |
| Material: | A105 | Model Number: | DN15-DN1200 |
|---|---|---|---|
| Standard Or No Standard: | Standard | Product Name: | Sorf/unrf/blind Flanges |
| Standard: | ANSI ,ASTM | Packing: | Wooden Case Or Pallets |
| High Light: | ANSI B16.5 SS Threaded Flange,ASTM SS Threaded Flange,A105 Stainless Steel Threaded Flange |
||
ANSI B16.5 Class 150/300/600/900/1500/2500 Stainless Steel SS Thread Threaded Flange
Flange, also known as flange plate or flange. Flanges are parts connecting pipes, which are used to connect pipe ends; It is also used for flanges on the inlet and outlet of equipment, which are used for connection between two equipment, such as reducer flange. Flange connection or flange joint refers to the detachable connection of flange, gasket and bolt as a group of combined sealing structures. The pipe flange refers to the flange used for piping in the pipeline device, and the inlet and outlet flanges of the equipment when used on the equipment. There are holes on the flange, and the bolts make the two flanges tightly connected. The flanges are sealed with gaskets. Flanges are threaded (threaded), welded and clamped. Flanges are used in pairs, screw flanges can be used for low pressure pipelines, and welding flanges can be used for pressure above 4 kg. Add a gasket between the two flanges and fasten them with bolts. Flanges with different pressures have different thicknesses, and they use different bolts. When pumps and valves are connected with pipes, parts of these equipment are also made into corresponding flange shapes, also known as flange connection. All connecting parts that are closed at the same time by bolt connection around two planes are generally called "flanges", such as the connection of ventilation pipes. Such parts can be called "flange parts". However, this connection is only a part of the equipment, such as the connection between the flange and the water pump, so it is not good to call the water pump a "flange part". Smaller ones, such as valves, can be called "flange parts"
| Name |
Flange
|
|
|
Size
|
Size 1/4” to 24”
|
|
|
Standard
|
API5
L , ASTM A106 Gr.B, ASTM A53 Gr.B,ANSI A210-1996, ANSI B36.10M-2004 , ASTM A1020-2002,ASTM A179-1990 ,BS 3059-2,DIN 17175 ,DIN
1630 ,DIN 2448 |
|
|
Material
|
GR.B,ST52, ST35, ST42, ST45,X42, X46, X52, X56, X60, X65, X70,SS304, SS316 etc.
|
|
|
Certificates
|
API5L, ISO 9001:2008,SGS, BV,CCIC
|
|
|
Wall thickness
|
SCH10, SCH20, SCH30, STD, SCH40, SCH60, SCH80, SCH100 SCH120, SCH160, XS, XXS
|
|
|
Surface Treatment
|
black paint, varnish, oil, galvanized, anti corrosion coatings.
|
|
|
Marking
|
Standard marking, or according to your request. Marking Method: Spray white paint
|
|
|
Pipe Ends
|
Under 2 inch plain end. 2 inch and above Beveled. Plastic caps (small OD) ,Iron protector (large OD)
|
|
|
Pipe Length
|
1. Single Random Length and double Random Length.
2. SRL:3M-5.8M DRL:10-11.8M or As clients requested length. 3. fixed length(5.8m, 6m, 12m) |
|
|
Packaging
|
Loose package; Packaged in bundles(2Ton Max); bundled pipes with two slings at the both end for easy loading and discharging; End
with Plastic caps; wooden cases. |
|
|
Test
|
Chemical Component Analysis, Mechanical Properties, Technical Properties, Exterior Size Inspection, hydraulic testing , X-ray
Test. |
|
|
Application
|
liquid delivery; Structure pipe; High and low pressure Boiler tube; Seamless steel tubes for petroleum cracking; oil pipe; gas
pipe. |
|
|
Delivery Time
|
7-15 days
|
|
|
Advantages
|
1.Reasonable price with excellent quality.
2.Abundant stock and prompt delivery. 3.Rich supply and export experience, sincere service. 4.Reliable forwarder, 2-hour away from port. |
